Machine Screws Non StandardM16 A2-70 Hex Socket Head Cap Screws With Black Surface Treatment

Machine Screws Non StandardM16 A2-70 Hex Socket Head Cap Screws With Black Surface Treatment

  • Machine Screws Non StandardM16 A2-70 Hex Socket Head Cap Screws With Black Surface Treatment
  • Machine Screws Non StandardM16 A2-70 Hex Socket Head Cap Screws With Black Surface Treatment
  • Machine Screws Non StandardM16 A2-70 Hex Socket Head Cap Screws With Black Surface Treatment
  • Machine Screws Non StandardM16 A2-70 Hex Socket Head Cap Screws With Black Surface Treatment
Machine Screws Non StandardM16 A2-70 Hex Socket Head Cap Screws With Black Surface Treatment
Product Details:
Place of Origin: China
Brand Name: HNF
Certification: ISO9001
Model Number: NON STANDARD
Payment & Shipping Terms:
Minimum Order Quantity: 2000 pcs
Price: Negotiation
Packaging Details: customize packing
Delivery Time: 14days
Payment Terms: L/C, T/T, D/A, Western Union
Supply Ability: 360 ton per month
Contact Now
Detailed Product Description
Product Name: Stainless Steel Machine Screws A2-70 Hex Socket Head Cap Machine Screws Full Thread Material: A2
Color: Plain Head Style: Allen Head, Hex Socket Head
Drive Style: Allen Drive Thread: Full Thread
Diameter: M16
High Light:

ss machine screws

,

flat head machine screw

Machine Screws Non StandardM16 A2-70 Hex Socket Head Cap Screws With Black Surface Treatment





1.Product Description



Socket caps have a small cylindrical head with tall vertical sides. Allen (hex socket) drive is a six-sided recess for use with an allen wrench (hex key). A tempered medium carbon steel. Grade 8 is stronger than grade 5, and is commonly found in high strength automotive applications.

Socket head cap screws supply high tensile strength than equivalent hex head caps screws, meanwhile requiring less surface area to countersunk head screws. Known as the Allen bolt or allen head screw. The same to the countersunk head screw, the head of the buried into the parts, which serves the greater strength of the connection. Socket head cap screws are ideal for precision work with close tolerances and applications whcih need a well tooled appearance. The material are normally Alloy Steel, Stainless Steel and Carbon Steel.Strength of the screw is by the head marking, defined by the applicable products' standard.While many hex cap screws may be found in vehicles, socket head screws are becoming more popular and have some space saving advantages over hex cap screws. Socket heads take up less space themselves and don't require side room for wrenches. They also are usually made from stronger alloy steel vs. hex cap screws, but this depends on the grade and manufacturer.

Most socket head screws accept a hex or Allen wrench (6 sided), but Torx heads (loosely, a 6 pointed star) are also available. Torx sockets were originaly designed to prevent the driver from camming out, and can transfer more torque than a Phillips or slotted driver. They don't require large amounts of pressure to keep the bit in the socket. Some people say that it's faster to insert a bit into a Torx screw than a hex socket, which would be advantageous in manufacturing environments.



2. Specification



Diameter

(mm)

Picth Thread Length(mm) Head Thickness(mm) Head Diameter (mm) Hex Width (mm) Socket Length(mm)
M16 2/ 1.5 60 15.57-16 23.67-24.33

14.032-14.21

8



More details:



Product Dimensions M16 x 60mm
Item Weight 130kg 1000 pieces
Standard DIN912-1983
Free Sample Available, shipping need to be charged
Thread type Full Thread/ Fine Thread
Advantages Easy to install, High Tensile, offer high holding power



3.Application



The hex socket head cap screws are durable and used in many industrial applications. Normally used for many machine tools and their accessories too. Mainly used for which does not allow screws or where the hex head screw hard to assembly and disassembly.



4.Advantages



Easy to install with allen wrench, buried into parts.With a high cylindrical head, socket cap head fasteners offer high holding power at high torque situation. it could offer greater tensile strength than equivalent hex head caps screws.



5.More pictures



Machine Screws Non StandardM16 A2-70 Hex Socket Head Cap Screws With Black Surface Treatment 0
